HOME > EQUIPMENT > Large Pump Truck
-
- Boom Specifications
-
| Vertical Reach |
36.5m |
119' 9'' |
| Horizontal Reach |
32.5m |
106' 8'' |
| Unfolding Height |
8.4m |
27' 7'' |
- General Specification
-
| Pipeline Diameter |
125mm |
5'' |
| Rotation |
370° |
| End Hose Length |
4m |
13' 2'' |
| End Hose Diameter |
125mm |
5'' |
| Outrigger Spread Front |
6.2m |
20' 4'' |
| Outrigger Spread Rear |
7.7m |
25' 3'' |
- Pump Specifications
-
| Output |
Rod Side |
150㎥/hr |
196 yd³/hr |
| Piston Side |
102㎥/hr |
133 yd³/hr |
| Pressure |
Rod Side |
87bar |
1,262 psi |
| Piston Side |
130bar |
1,886 psi |
| Concrete Cylinder Diameter |
230mm |
9'' |
| Stroke Length |
2,100mm |
6' 11'' |
| Maximum Strokes per Minutes |
Rod Side |
29 |
| Piston Side |
19 |
| Hopper Capacity |
600L |
21.2 ft³ |
| Volume Control |
Zero to full |
| Hydraulic System |
Closed-loop |
| Hydraulic System Pressure |
350bar |
5,075 psi |
| Differential cylinder diameter |
140mm |
5.5'' |
| Rod Diameter |
80mm |
3'' |
| Water Tank Capacity |
500L |
132 gal |
| Water Pump Pressure |
20bar |
290 psi |
- Truck Mounted Specifications
-
| Truck |
CL7CR(DAEWOO) |
| Length |
11,990m |
39' 4'' |
| Width |
2,490mm |
8' 2'' |
| Height |
3,920mm |
12' 10'' |
| Wheelbase |
5,600mm |
18' 3'' |
| Total Weight |
25,600kg |
56,438 lbs |
