- STIFF BOOM CRANE
-
| Category |
Description |
Unit |
SS1404
(STD) |
SS1406
(TOP , STD) |
SS1506 ACE
(TOP , STD) |
SS1924
(TOP , STD) |
SS1926
(TOP , STD) |
| Capacity |
Max. Lifting Capacity |
kg.m |
14,000 |
14,000 |
15,000 |
18,000 |
19,000 |
| Max. Working Height |
m |
13.6 |
18.3(21.7) |
22.3(25.4) |
16.5 |
22.7(25.9, 27.6) |
| Max. Working Radius |
m |
11.2 |
16.3 |
19.4(22.6) |
13.6 |
19.8(23.0, 24.8) |
Rated Load
(★:6S, Sth:4S) |
kg/m |
★6,000/2.0 |
★6,000/2.0 |
★7,000/2.0 |
★7,000/2.7 |
★7,000/2.7 |
| 3,500/3.8 |
3,500/4.0 |
3,750/4.7 |
3,900/4.5 |
3,900/4.7 |
| 2,000/6.3 |
2,000/6.5 |
2,000/7.6 |
2,100/7.6 |
2,100/7.7 |
| 1,300/8.8 |
1,300/9.0 |
1,150/10.5 |
1,250/10.6 |
1,250/10.7 |
| 950/11.2 |
950/11.4 |
800/13.5 |
850/13.6 |
850/13.7 |
| |
750/13.9 |
530/16.5 |
|
600/16.8 |
| |
500/16.3 |
370/19.4 |
|
400/19.8 |
| Oil Pump |
Rated Oil Flow Volume |
ℓ/min. |
70 |
70 |
70 |
80 |
80 |
| Oil Pressure |
kgf/㎠ |
200 |
200 |
200 |
210 |
210 |
| Oil Tank Capacity |
ℓ |
100 |
100 |
120 |
120 |
120 |
Booms
&
Wires |
Boom Type / Sections |
|
Hexa / 4 |
Hexa / 6 |
Hexa / 6 |
Hexa / 4 |
Hexa / 6 |
| Boom Extending Speed |
m/sec. |
7.5/22 |
12.3/32 |
14.7/34 |
8.9/28 |
15.1/36 |
| Boom Undulation Speed |
deg./sec. |
78/11 |
78/12.5 |
80/16 |
80/15 |
80/17 |
| Wire Rope |
|
Φ10x90m |
Φ10x90m |
Φ10x100m |
Φ10x100m |
Φ10x100m |
| Winch Speed |
m/min. |
14/4 layer |
14/4 layer |
14/4 layer |
14/4 layer |
15/4 layer |
| Swing Angle |
deg. |
360 Swirl |
360 Swirl |
360 Swirl |
360 Swirl |
360 Swirl |
| Swing Speed |
rpm |
2.5 |
2.5 |
2.5 |
2.5 |
2.5 |
| Outrigger |
Outrigger Extend Width |
m |
Front |
5.7 |
5.7 |
5.7 |
5.7 |
5.7 |
| Rear |
4.4 |
4.4 |
4.4 |
4.4 |
4.4 |
| Outrigger Type |
|
Front |
Auto hydraulic |
Auto hydraulic |
Auto hydraulic |
Auto hydraulic |
Auto hydraulic |
| |
Rear |
Auto hydraulic |
Auto hydraulic |
Auto hydraulic |
Auto hydraulic |
Auto hydraulic |
| Vehicle |
Mountable Vehicle |
Payload |
over 4.5 ton |
over 4.5 ton |
over 5ton |
over 5ton |
over 5ton |
| Safety Devices |
Load Indicator, Hydraulic Safety Valves,Counter balance Valves, Pilot Check Valves
Winch Brake, Swing Brake, Hook Safety Latch, Swing Locking Pin
Level Gauge(Option),Overwinding Alarm Device(Option)
Overwinding Limit and Overloading Limit Device(Option) |
| Options |
Extra Boom,Extra Winch,Oil Cooler, Two stage Front Outrigger,
Long-Long Front Outrigger,Top Seat |
| Category |
Description |
Unit |
SS2036
(TOP , STD) |
SS2037
(TOP , STD) |
SS2724
(STD) |
SS2725
(TOP , STD) |
SS2725LB
(TOP , STD) |
SS3504
(TOP , STD) |
SS3506
(TOP) |
SS6506 |
| Capacity |
Max. Lifting Capacity |
kg.m |
19,000 |
18,000 |
29,000 |
29,000 |
29,000 |
45,000 |
45,000 |
61,000 |
| Max. Working Height |
m |
22.7(25.9, 27.6) |
25.6(28.8, 30.5) |
17.9(21.8) |
20.8(24.7) |
23.2(27.1) |
19.6(23) |
28.7(32.6) |
32 |
| Max. Working Radius |
m |
19.8(23.0, 24.8) |
22.6(25.8, 27.6) |
14.5(18.5) |
17.6(21.6) |
20.2(24.2) |
17.2(21.2) |
25.2(29.2) |
28.5 |
Rated Load
(★:6S, Sth:4S) |
kg/m |
★8,000/2.0 |
★8,000/2.0 |
★10,000/3.0 |
★10,000/3.0 |
★10,000/3.0 |
★15,000/3.0 |
★15,000/3.0 |
★17,500/3.0 |
| 3,900/4.7 |
3,500/4.7 |
5,600/5.0 |
5,600/5.0 |
5,500/5.4 |
7,500/6.0 |
7,500/6.0 |
8,900/7.0 |
| 2,100/7.7 |
1,800/7.8 |
3,250/8.2 |
3,250/8.2 |
2,900/9.1 |
4,000/9.9 |
4,000/9.9 |
4,550/11.3 |
| 1,250/10.7 |
1,000/10.8 |
2,350/11.3 |
2,350/11.3 |
1,700/12.8 |
2,500/13.7 |
2,500/13.7 |
2,700/15.6 |
| 850/13.7 |
750/13.8 |
1,700/14.5 |
1,700/14.5 |
1,250/16.5 |
1,750/17.6 |
1,750/17.6 |
1,900/19.9 |
| 600/16.8 |
530/16.7 |
|
1,100/17.6 |
950/20.2 |
|
1,300/21.4 |
1,300/24.2 |
| 400/19.8 |
250/22.6 |
|
|
|
|
10,00/25.3 |
920/28.5 |
| Oil Pump |
Rated Oil Flow Volume |
ℓ/min. |
80 |
80 |
90x90 |
90x90 |
90x90 |
126x126 |
126x126 |
126x126 |
| Oil Pressure |
kgf/㎠ |
210 |
210 |
210 |
210 |
210 |
210 |
210 |
210 |
| Oil Tank Capacity |
ℓ |
170 |
170 |
200 |
200 |
200 |
250 |
250 |
250 |
| Booms Wires |
Boom Type/Sections |
|
Hexa / 6 |
Hexa / 7 |
Hexa / 4 |
Hexa / 5 |
Hexa / 5 |
Hexa / 6 |
Hexa / 6 |
Hexa / 6 |
| Boom Extending Speed |
m/sec. |
15.1/36 |
17.8/36 |
12.7/30 |
12.7/30 |
14.8/35 |
19.2/48 |
19.2/48 |
19.2/48 |
| Boom Undulation Speed |
deg./sec. |
-17~80/19 |
-17~80/18 |
78/18 |
78/18 |
78/18 |
80/23 |
80/23 |
-12~80/23 |
| Wire Rope |
|
Φ10x100m |
Φ10x100m |
Φ12.5x100m |
Φ12.5x100m |
Φ12.5x100m |
Φ14x100m |
Φ14x100m |
Φ14x100m |
| Winch Speed |
m/min. |
15/4 layer |
15/4 layer |
30~60/1 layer |
30~60/1 layer |
30~60/1 layer |
30~120/1 layer |
30~120/1 layer |
30~120/1 layer |
| Swing Angle |
deg. |
360 Swirl |
360 Swirl |
360 Swirl |
360 Swirl |
360 Swirl |
360 Swirl |
360 Swirl |
360 Swirl |
| Swing Speed |
rpm |
2.5 |
2.5 |
2.5 |
2.5 |
2.5 |
2.0 |
2.0 |
1.5 |
| Outrigger |
Outrigger Extend Width |
m |
Front |
6.1 |
6.1 |
6.2 |
6.2 |
6.2 |
7 |
7 |
7 |
| Rear |
4.4 |
4.4 |
5.36 |
5.36 |
5.36 |
5.36 |
5.36 |
5.43 |
| Outrigger Type |
|
Front |
Auto hydraulic |
Auto hydraulic |
Auto hydraulic |
Auto hydraulic |
Auto hydraulic |
Auto hydraulic |
Auto hydraulic |
Auto hydraulic |
| |
Rear |
Auto hydraulic |
Auto hydraulic |
Auto hydraulic |
Auto hydraulic |
Auto hydraulic |
Auto hydraulic |
Auto hydraulic |
Auto hydraulic |
| Vehicle |
Mountable Vehicle |
Payload |
over 5ton |
over 5ton |
over 11ton |
over 11ton |
over 11ton |
over 15ton |
over 15ton |
over 15ton |
| Safety Devices |
Load Indicator, Hydraulic Safety Valves,Counter balance Valves, Pilot Check Valves
Winch Brake, Swing Brake, Hook Safety Latch, Swing Locking Pin
Level Gauge(Option),Overwinding Alarm Device(Option)
Overwinding Limit and Overloading Limit Device(Option) |
| Options |
Extra Boom,Extra Winch,Top Seat |
Extra Boom,Extra Winch,
Middle Outrigger,Top Seat |
Extra Boom,Extra Winch,Middle Outrigger,
Top Seat (SS3506, SS6506 Only) |
